Scanning mode : electronic convex array
Cineloop : 100 frame
Battery : 6000 mAh, maximum 4.5-hour continuous use
Display mode : B/C/M/PW/PD/PWD
Warranty : 1 year
Language : English/Chinese
Element : 128
Output : HDMI video
G/W : 480g
Product Name : Easy-to-carry CE Marked Wireless Ultrasound Probe for Primary Care
Brand Name : Golead
Model Number : S35C
Certification : CE, ISO13485
Place of Origin : China
MOQ : 1 Unit
Payment Terms : T/T
Supply Ability : 1,000 units per month
Delivery Time : 2 working days
Packaging Details : carton box
Frequency : 2/3.6/5MHz
N/W : 280g
A convex probe is a type of ultrasound transducer that is widely used in various clinical settings, particularly in point-of-care ultrasound (POCUS) exams. The convex probe has a curved or convex shape, which enables it to provide a wider field of view than other types of probes, such as linear or phased array probes.
| Model | Handheld ultrasound scanner S35C |
|---|---|
| Scanning mode | Electronic Convex Array with 128 elements |
| Display mode | B/C/M/PW/PD |
| Central frequency | 3.6MHz |
| Depth | 378mm |
| Zoom | 4 times |
| Channel | 32 |
| Dynamic Range | Max 180dB |
| Sampling Rate | 50MHz |
| Gray | 256 |
| FPS | 8 to 30 |
| Packing Dimension | 255*190*60 mm |
| Battery | 3,000 mAh |
|
|
